| Specifications | |||
| Number of pins: | 19 Pins | Key Position: | A Coded |
| Left Connector: | AVIATION Plug | Right Connector: | - |
| AWG Gauge: | 20 AWG ~ 24 AWG | Connection Type | Screw Locking |
| Wires & Cables Length: | Customized length | ||
| Material | |||
| Housing & Insulation: | PA 66, Black | Contacts: | Copper Alloy,Gold-Plated |
| Shell: | Aluminum alloy, Military green | Sealing: | NBR |
| Shielding: | Yes | Overmolding: | Optional |
| Wires & Cables Conductor: | Tinned Copper | Wires & Cables Jacket: | PVC | TPU |
| Technical Characteristics | |||
| Rated Current: | 4A | Rated Voltage: | 600V |
| Rated Temperature | -55°C ~ + 125°C | Flame Retardant Grade: | VW-1 |
| Insulation Resistance: | ≥ 500 MΩ | Contact Resistance: | ≤3mΩ |
| Durability: | ≥ 500 Times | Protection Grade: | IP67 |
| Product Certification: | - | Production Design Standards: | MIL-DTL-38999 |
| Application | |||
